Details: Coreweld 46 LS

Use for the welding of thin-plate with a minimum thickness of 1.0 mm and provides fabricators with a substantially faster and higher quality welding solution to solid MAG wire. The absence or very low levels of silica on the weld surface and minimal spatter result in reduced post weld cleaning before coating/painting.

Usage: robotic fabrication.

Typical Tensile Properties

As welded
Elongation	Tensile Strength	Yield Strength
29 %	545 MPa	485 MPa



Charpy V-Notch Properties

As welded
Impact Value	Testing Temperature
72 J	-40 °C



Weld Metal Analysis

Mn	C	Si	Ni
1.25 %	0.04 %	0.63 %	0.35 %



Deposition Data

Diameter	Current	Deposition Rate	Voltage	Wire Feed Speed
1.4 mm	150-380 A	1.8-7.0 kg/h	18-34 V	2.5-9.0 m/min
1.2 mm	100-360 A	1.3-8.0 kg/h	16-32 V	1.8-13.0 m/min
1.6 mm	150-450 A	1.7-7.8 kg/h	17-36 V	2.0-9.3 m/min



Approvals:	ABS, 4Y40M H5 (M20), ABS, 4Y40M H5 (M21), BV, 4Y40 H5 (M20), (1.2mm), BV, 4Y40 H5 (M21), (1.2mm), CE, EN 13479, DB, 42.039.38, (1.2mm), DNV, IV Y40MS(H5) (M20), DNV, IV Y40MS(H5) (M21), GL, 4Y40H5S (M20), (1.2mm), GL, 4Y40H5S (M21), (1.2mm), VdTÜV, 12152, (1.2mm)
Classifications:	SFA/AWS A5.36, E71T15-M20A4-CS1 H4, Weld Metal, SFA/AWS A5.36, E71T15-M21A4-CS1 H4, Weld Metal, EN ISO 17632-A, T 46 4 M M20 2 H5, Weld Metal, EN ISO 17632-A, T 46 4 M M21 2 H5, Weld Metal

---



Alloy Type:	C Mn steel
Diffusible Hydrogen:	< 4 ml/100g
Welding Current:	DC+
