Estimated Maximum Cutting  for Mildsteel/ Carbon Steel: 30 mm

Estimated Maximum Cutting  for Stainless Steel : 14 mm ( Severance cut )

Items Included :  Plasma Cutting Torch , Clamp , Glove, Headshield.

Warranty 2 years ( Wear & Tear not included)

Specifications :

Rated Input Voltage(V)：AC380V±15% 3P

Efficiency(%)：85

Input Frequency (HZ)：50/60

Power Factor：0.93

Rated Input Power(KVA)：11.3

Protection Grade：IP21

Rated Input Current(A)：18

Arc-Initiating：H-F,Untouch

Open Circuit Voltage(V)：268

Air Pressure(MPa)：0.4-0.5

Current Range(A)：20-80

Rated Output Voltage（V）：112

Weight(kg)：28.7 ( Does not include accessories )

Duty cycle at maximum current：60%@40℃

Dimension(mm)：515x262x468
