Cigweld/victor has always been a partner with Delta Welding. More than 20 years in experience, We are more than happy to represent Cigweld Australia products in is product for welding. Categorized as a pioneer in the welding industry, we will assist in sales and technical support. Delta Welding will only accept qualified and certified welding products.

Items given: T.B.A

• 7Ft. (2.1M) 360 degree swivel cable & insulated hook-up kit
• Heavy-duty insulators, lever, and handle that are all made from fiberglass reinforced thermoset polyester molding compound to withstand the heat and be impact resistant.
• Forged 1-piece brass alloy body machined to close tolerances on the valve & head seat.
• Head assembly machined from copper alloy having four (4) air holes optimizing the air flow to the arc.
• Balanced to pivot at the center of the handle for ease of use for all gouging positions, and thereby reduces operator fatigue.
• Lever spring rated at 146 lbs. per inch providing excellent clamping pressure on the air carbon-arc electrode.

• Applications: Medium-Duty Fabrication / Maintenance / Railroad / Shipyard
• Amerage CapacitY: Up to 600 Amps
• Carbon Electrode Range Pointed / Jointed: 5/32″ (4.0mm) to 3/8″ (9.5mm)
• Flat: 3/8″ (9.5mm) x 5/32″ (4.0mm)
• Flat: 5/8″ (15.9mm) x 3/16″ (4.8mm)
• Air Requirement Pressure: 80 psi (5.6kg/cm2)
• Flow Rate: 22 cfm (624 L/Min)
• Weight 7.2 lbs (3.27kg)

• Up to 1 Year Warranty Period
